0.5HP 110V Pressure Tank Booster System - North America Home Water Supply

0.5HP 110V Pressure Tank Booster System - North America Home Water Supply

The NOVAPUMP 0.5HP 110V Pressure Tank Booster System is a complete, pre-assembled water pressure solution engineered specifically for North American residential homes. This plug-and-play system combines a powerful 110V booster pump with an 8-liter pressure tank and automatic pressure controller, delivering consistent water pressure to every outlet in the house without the complexity and cost of a full well-pump replacement.

Technical Specifications

• Power: 0.5HP (370W)
• Voltage: 110V / 60Hz (UL certified motor)
• Max Flow Rate: 60 L/min (15.8 GPM)
• Max Head: 35 meters (115 ft)
• Pressure Tank: 8 liter (2.1 gallon) pre-pressurized steel tank
• Pressure Switch Range: 1.5-3.0 bar (adjustable)
• Inlet/Outlet: 1 inch NPT threaded
• Motor: Capacitor-start induction motor, IP44 rated
• Shipping Weight: 14 kg (complete system)

Key Features

• Complete System: Includes pump, pressure tank, pressure switch, gauge, and 5-way connector - ready to connect to existing plumbing
• 110V North American Standard: Designed for standard US/Canada electrical outlets - no electrician required
• Automatic Operation: Pressure switch starts pump when pressure drops below 1.5 bar, stops at 3.0 bar
• Pre-Pressurized Tank: Reduces pump cycling by 70%, extending motor life and saving energy
• Quiet & Efficient: Induction motor operates at <60 dB with 85% efficiency rating

Applications

Whole-house pressure boost for municipal water supply, well water pressure systems, RV and mobile home water supply, garden irrigation booster, and car wash pressure systems.

FAQs

Q: Can this replace my well pump?
This is a booster pump, designed to increase existing water pressure. For well pumping from depth, consider our submersible pump range.

Q: Does it require a dedicated circuit?
Recommended: 15A dedicated circuit. The pump draws 5.5A running current, 8A startup.

Q: What is included in the box?
Pump unit, 8L pressure tank, pressure switch, pressure gauge, 5-way brass connector, installation manual, mounting bolts.

CE & UL Certified | 12-Month Warranty | Free Installation Support
