0.75HP SS304 Horizontal Magnetic Drive Centrifugal Pump - OEM Custom

0.75HP SS304 Horizontal Magnetic Drive Centrifugal Pump - OEM Custom

The NOVAPUMP 0.75HP SS304 Magnetic Drive Centrifugal Pump offers zero-leak chemical transfer with the durability of full 304 stainless steel construction. Unlike traditional sealed centrifugal pumps, the magnetic drive eliminates shaft seals entirely, making this pump ideal for corrosive chemicals, high-purity liquids, and applications where even minor leakage is unacceptable. Available for OEM integration with custom voltage, port configuration, and mounting options.

Technical Specifications

• Power: 0.75HP (550W)
• Voltage: 220V/380V three-phase or 220V single-phase (customizable)
• Max Flow Rate: 200 L/min (52.8 GPM)
• Max Head: 18 meters (59 ft)
• Inlet/Outlet: 1-1/2 inch ANSI flange (DN40)
• Motor: TEFC induction, IE3 premium efficiency
• Wetted Materials: 304 stainless steel casing, PTFE/PFA bushings, ceramic thrust bearing
• Mag Drive: Neodymium rare-earth magnets, hermetically sealed
• Max Fluid Temperature: 120 C (248 F)
• Weight: 16 kg

Key Features

• Zero-Leak Design: Magnetic coupling eliminates shaft seals - no mechanical seal to wear or leak
• Full 304 SS Construction: Entire pump casing, impeller, and magnet housing in 304 stainless steel
• Dry-Run Tolerant: Ceramic thrust bearing tolerates brief dry-running without immediate damage
• OEM Customization: Available with custom voltage, flange standards (ANSI/DIN/JIS), and mounting configurations
• IE3 Premium Efficiency: 15% more energy-efficient than standard IE2 motors

Applications

Chemical transfer (acids, alkalis, solvents), high-purity water circulation, electroplating solution transfer, pharmaceutical process fluids, and food-grade liquid transfer.

FAQs

Q: What chemicals can this pump handle?
The 304 SS and PTFE wetted parts handle most acids (except HCl and H2SO4 above 10%), alkalis, and organic solvents. Contact us for a full chemical compatibility chart.

Q: Can it run dry?
Brief dry running (under 2 minutes) is tolerated. Extended dry running will damage the ceramic thrust bearing. A dry-run protection switch is recommended.

Q: What is the minimum order quantity for OEM customization?
MOQ 20 units for custom voltage/flange. MOQ 100 units for custom color and branding.

CE & ISO 9001 Certified | 12-Month Warranty | OEM & ODM Service Available
