1 Inch Aluminum AODD Pump Kit - Complete with Regulator & Fittings

1 Inch Aluminum AODD Pump Kit - Complete with Regulator & Fittings

The NOVAPUMP 1 Inch Aluminum Air-Operated Double Diaphragm (AODD) Pump Kit arrives ready to operate - no additional parts required. This complete kit includes the aluminum AODD pump, air filter-regulator-lubricator (FRL) unit, inlet/outlet connection kit, and a spare diaphragm set. Engineered for general industrial fluid transfer, this pump handles everything from wastewater and sludge to solvents and viscous fluids up to 10,000 cP.

Technical Specifications

• Size: 1 inch inlet/outlet
• Max Flow Rate: 150 L/min (39.6 GPM)
• Max Head: 84 meters (276 ft)
• Max Suction Lift (Dry): 5 meters
• Max Suction Lift (Wet): 8 meters
• Air Supply: 1-8 bar (14-116 PSI), 1/2 inch air inlet
• Max Solids: 6 mm diameter
• Max Viscosity: 10,000 cP
• Body Material: Aluminum alloy, anodized
• Diaphragm: Santoprene (Buna-N, PTFE, Viton available)
• Kit Includes: Pump, FRL unit, 1'' camlock connectors, 2m air hose, spare diaphragms
• Weight: 11 kg (complete kit)

Key Features

• Complete Turnkey Kit: Everything needed in one box - pump, FRL, connectors, hoses, spares
• Run-Dry Safe: AODD pumps tolerate indefinite dry running without damage
• Dead-Head Capable: Can operate against a closed discharge valve without overheating
• Self-Priming: Automatically primes up to 5 meters dry suction lift
• Explosion-Proof: Air-operated with no electrical components - safe for flammable environments

Applications

Wastewater transfer, sump dewatering, paint and coating transfer, oil and fuel transfer, chemical dosing, mining slurry, and tank unloading.

FAQs

Q: What air compressor size is needed?
A 3HP / 200L compressor (minimum 300 L/min free air delivery). Larger pumps require proportionally larger compressors.

Q: Are different diaphragm materials available?
Yes. Santoprene (standard), Buna-N (oil resistant), PTFE (chemical resistant), and Viton (high temperature to 175 C) available.

Q: Can it pump solids?
Yes, up to 6mm diameter solids pass through the 1 inch valve ports without clogging.

CE Certified | 12-Month Warranty | Spare Parts Kit Included | 48-Hour Express Shipping
