2HP Horizontal Multistage Booster Pump - Commercial Building Water Pressure System

The NOVAPUMP 2HP Horizontal Multistage Booster Pump delivers industrial-grade water pressure for commercial buildings, hotels, and small manufacturing facilities. The horizontal multistage design provides 75 meters of head in a service-friendly layout with easy access to the motor, mechanical seal, and pump stages. Stainless steel stamped components ensure high efficiency and corrosion resistance for potable water and light industrial applications.

Technical Specifications

• Power: 2HP (1.5kW)
• Voltage: 220V/380V three-phase or 220V single-phase
• Max Flow Rate: 8,000 L/h (35.2 GPM)
• Max Head: 75 meters (246 ft)
• Stages: 5 (expandable to 8)
• Inlet/Outlet: 1.5 inch threaded (horizontal inline)
• Motor: IE3 premium efficiency, IP55, Class F, foot-mounted
• Pump Sections: 304 SS stamped impellers and diffusers
• Shaft: 304 SS with cartridge mechanical seal
• Base Frame: Steel channel with anti-vibration mounts
• Noise Level: <68 dB
• Weight: 35 kg

Key Features

• Commercial Capacity: 8,000 L/h at 75m head - serves buildings up to 18 floors or multiple commercial units
• IE3 Premium Efficiency: Reduces energy costs by 22% compared to standard motors, paying back the price premium within 18 months
• Cartridge Seal: Pre-assembled mechanical seal cartridge for 15-minute replacement without pump disassembly
• Horizontal Service Layout: All components accessible from floor level without lifting equipment
• VFD Ready: Designed for variable speed operation with external VFD for demand-based pressure control

Applications

Hotel water pressure boosting, commercial building domestic water supply, hospital water systems, school and university campus water, and light industrial process water circulation.

FAQs

Q: Can it be used for potable water?
Yes. All wetted parts are 304 stainless steel and food-grade EPDM seals. WRAS certification available on request.

Q: What is the service interval?
Cartridge mechanical seal replacement at 8,000 hours. Bearing re-greasing every 2,000 hours. Annual performance check recommended.

Q: Can multiple pumps be combined?
Yes. Parallel configuration for higher flow. Series configuration for higher pressure. Common base frame available for pump sets.

CE & ISO 9001 Certified | 12-Month Warranty | Free Pump Room Layout Design
