2HP Solar AC/DC Hybrid Submersible Water Pump - 120m Head Farm Irrigation

2HP Solar AC/DC Hybrid Submersible Water Pump - 120m Head Farm Irrigation System

The NOVAPUMP 2HP Solar AC/DC Hybrid Submersible Pump provides the perfect solution for farms that need reliable deep-well water with the flexibility of dual power sources. At 120 meters maximum head and 6,500 L/h flow, this pump irrigates 5-8 hectares. Solar priority mode reduces electricity costs by up to 80%, while seamless grid backup ensures water never stops - critical for livestock and crop irrigation.

Technical Specifications

• Power: 2HP (1.5kW)
• Solar Input: 96-144V DC (recommended 6 x 350W panels)
• Grid Input: 220V AC single-phase (auto-switching)
• Max Flow Rate: 6,500 L/h (28.6 GPM)
• Max Head: 120 meters (394 ft)
• Motor: PMSM hybrid, oil-filled, IP68, Class H insulation
• Pump Body: 304 SS, multistage centrifugal, 8 stages
• Min Well Diameter: 4 inches (100mm)
• Controller: Hybrid MPPT/AC, IP65, LCD with kWh metering
• Hybrid Mode: Solar priority, grid supplement, or forced grid
• Weight: 18 kg

Key Features

• Solar Priority Mode: Uses maximum available solar power, only drawing grid power to make up the shortfall - saves 60-80% on electricity
• Built-in kWh Meter: Controller displays real-time and cumulative energy consumption from solar vs grid - track your savings
• Forced Grid Mode: For night irrigation or maintenance flushing when solar is unavailable
• Generator Compatible: Accepts generator AC input with voltage stabilization for rural areas with unstable grid
• SMS Alert Option: Optional GSM module sends SMS alerts for faults, low flow, or power interruptions

Applications

Medium-scale farm irrigation (5-8 hectares), orchard drip irrigation, livestock water supply, fish farm aeration and exchange, and rural community water systems.

FAQs

Q: How much electricity can I save?
In tropical regions with 6+ peak sun hours, the solar priority mode covers 70-80% of daily energy needs. Typical annual saving: 6,000-8,000 kWh.

Q: Can the grid input handle unstable voltage?
Yes, the controller includes a voltage stabilizer accepting 180-260V AC input - suitable for rural grids with voltage fluctuations.

Q: What is the total system cost vs pure grid pump?
Payback period is typically 2-3 years through electricity savings, after which water pumping cost is near-zero for the remaining 15+ year pump life.

CE Certified | 12-Month Warranty | 3-Year Motor Warranty | Free ROI Calculation
