2HP Vertical Magnetic Drive Pump - High Head Chemical Circulation 40m

2HP Vertical Magnetic Drive Pump - High Head Chemical Circulation 40m

The NOVAPUMP 2HP Vertical Magnetic Drive Pump delivers high-head chemical circulation with zero leakage in a space-saving vertical configuration. The magnetic coupling eliminates mechanical seals entirely, making this pump ideal for hazardous, corrosive, and high-purity chemical transfer where even minor leakage is unacceptable. The vertical design minimizes floor space and simplifies piping in crowded chemical process installations.

Technical Specifications

• Power: 2HP (1.5kW)
• Voltage: 220V/380V three-phase (50Hz) or 220V single-phase
• Max Flow Rate: 30,000 L/h (132 GPM)
• Max Head: 40 meters (131 ft)
• Inlet/Outlet: 2 inch ANSI flange (DN50)
• Motor: IE3 premium efficiency, IP55, vertical flange-mounted
• Wetted Materials: 304 SS or PVDF casing (select at order), PTFE bushings, SiC thrust bearing
• Mag Drive: Samarium-cobalt rare-earth magnets, hermetic containment shell
• Max Fluid Temperature: 150 C (302 F) with SS casing
• Max System Pressure: 16 bar (232 PSI)
• Weight: 48 kg

Key Features

• Zero Mechanical Seal: Magnetic drive eliminates shaft seals - no leakage, no seal replacements, no emissions
• Vertical Space-Saving: Compact footprint (30x30cm) fits tight chemical process layouts
• High-Temperature Capable: SS casing version handles fluids to 150 C - ideal for hot chemical transfer and thermal oil
• Dry-Run Tolerant: SiC (silicon carbide) thrust bearing tolerates brief dry-running - 10x more wear-resistant than carbon bearings
• Rare-Earth Magnets: Samarium-cobalt magnets maintain coupling strength at elevated temperatures where neodymium magnets weaken

Applications

Chemical plant circulation loops, heat transfer fluid pumping, high-purity DI water systems, corrosive fume scrubber circulation, and pharmaceutical solvent transfer.

FAQs

Q: PVDF or SS casing - which should I choose?
PVDF for strong acids (HCl, H2SO4, HNO3) and ultra-pure chemicals. 304 SS for high-temperature applications, alkalis, and general chemical transfer.

Q: What happens if the pump runs dry?
The SiC thrust bearing tolerates up to 5 minutes of dry running without damage. Beyond that, the containment shell may overheat from eddy currents.

Q: Can it handle solids or slurries?
No. Magnetic drive pumps require clean liquids. Solid particles will score the SiC bearing and reduce coupling efficiency.

CE & ISO 9001 Certified | 12-Month Warranty | Free Chemical Compatibility Review
